Features
  • Flame treatment with auto ignition.
  • 4/6 color printing in single pass.
  • Precise registration.
  • Lower ink consumption.
  • Variable speed AC drive for easy loading and unloading.

    • Optional
  • Zeromax Drive for auto ink control.
  • Magnetic Cylinder from USA
  • Offline Registration.
  • Maintenance Free Ink Distribution System.
    • Specifications
    Unit Value
    Min. & Max Dia. 60mm x 140mm
    Min. & Max. Height 50mm x 150mm
    Max Print Area 425mm (L) x 150mm (H)
    Electric Motor Drive Ac Gear motor 3 HP, 3 Phase, 50Hzs. with inverter for fine speed control
    Pneumatic Pressure @8-10 kg/cm2
    Air Consumption @12m3/hr
    Total Power Consumption 5 kilowatts
    Max. Impression @ 2500/hr
    Total Machine Weight 3000 kgs
    Product Samples
